Astra 2E: Western Europe Reports

lovelyperson

lovelyperson

Dreamer
Messages
892
Location
Alicante, España
My Satellite Setup
2.0m PF dish
1.8m PF Famaval
1.8m PF Marrafa
1.4m Tecatel offset
1.2m dish + Stab HH120
1.0m dish fixed 19.2ºE(Movistar-Spain etc)
TBS 5925 USB
TM5502, TM5402 mk3,
Octagon SX88,
Edision Primo IP S2
60.0ºE - 63.0ºW
My Location
Alicante, España
BBC HD transponders just switched to 3/4 FEC. Anyone having trouble receiving them now?
Morning 'H'......trust and hope life is good for yourself...........'J'

Here at the mo all ok.


TonyilCapo

TonyilCapo

Member
Messages
64
Location
над холмами и далеко
My Satellite Setup
Dishes: PF (restored Famaval) 2.4m 28.2E, offset 60cm 30W, 90cm 13E+19E, spares 80cm+1.15m
STBs: Vu+ Vu+ Duo2 DVBS2 x4 1TB HDD, GI Avatar2 DVBS2 x2, Vu+Zero
My Location
Central Portugal
I didn't even notice before reading this...
Right now I got 13dB on 10847 (BBC 1&2 HD), and 10.8dB on 11024 (BBC 4 HD), still using that universal LNBF I mentioned before...
Signal fluctuation is very little for me on these transponders.

R

rodscha

Member
Messages
250
Location
carcassonne south France(Languedoc)
My Satellite Setup
See signature
My Location
carcassonne south france,700ks south of Paris ,300k N of Barcelona
In Carcassonne south France,
i get 10847 45-65% jumpy (green line jumpy red line stable)
11024 32-45% jumpy (as above)
and 11123V(C4HD) 72% stable rock steady..
is that normal doctor?

N

Nalleman

Member
Messages
96
Location
Motala Sweden
My Satellite Setup
1,8 Channel Master, Black Pro LNB with CM feedhorn and VU+ DUO 2 and Vantage 8000 TS receivers. Fixed dishes at: 28,2/28,5 E, 19,2 E, 13 E, 9 E and 1 W
My Location
Sweden
All BBC (also SD)?

Or only BBC-HD?

greetz,
A33

SD:s have used FEC 5/6 for a long time. No change there.

Last edited:
N

Nalleman

Member
Messages
96
Location
Motala Sweden
My Satellite Setup
1,8 Channel Master, Black Pro LNB with CM feedhorn and VU+ DUO 2 and Vantage 8000 TS receivers. Fixed dishes at: 28,2/28,5 E, 19,2 E, 13 E, 9 E and 1 W
My Location
Sweden
BBC HD transponders just switched to 3/4 FEC. Anyone having trouble receiving them now?
No problem here with 10 847 V. 11 023 H has been tricky since 11 038 V was activated. Need to adjust the skew but haven´t bothered with it yet.

R

rodscha

Member
Messages
250
Location
carcassonne south France(Languedoc)
My Satellite Setup
See signature
My Location
carcassonne south france,700ks south of Paris ,300k N of Barcelona
10847 works better now,65-70% only slightly jumpy... better propagation or increased signal?
Nice,anyway

superpascu2

superpascu2

Member
Messages
95
My Satellite Setup
ATLAS HD100 - ASTRA 19,2 + HOTBIRD 13 + 28,2 1.2m famaval
My Location
Alicante
BBC HD transponders just switched to 3/4 FEC. Anyone having trouble receiving them now?
Nothing noticed on a favamal 1,1m in Alicante, same as always on 10847V

K

kabiela

Member
Messages
1
My Satellite Setup
dreambox 800
My Location
belgie
scan the satellite 28.2 ° E completely back in
you will get a picture again on bbc etc.


Attachments

Last edited:
Analoguesat

Analoguesat

Administrator
Staff member
Messages
46,782
Location
Scottish Borders
My Satellite Setup
TM 5402HD
Skybox F3
Sky+ UK.
My Location
Scottish Borders
scan de satelliet 28.2 ° E volledig terug in
je krijgt opnieuw een foto op bbc enz.

scan the satellite 28.2 ° E completely back in
you get another picture on bbc etc.


Welkom op het forum. Plaats alsjeblieft in het Engels op dit forum, een google vertaling is acceptabel.
Welcome to the forum. Please post in English on this forum, a google translation is acceptable.

Huevos

Huevos

Satellite Freak
Messages
5,994
My Satellite Setup
57E to 58W, C-band and Ku, DVB-S2, 4:2:2 and blindscan.
My Location
38.5ºN, 0.5ºW
Morning 'H'......trust and hope life is good for yourself...........'J'

Here at the mo all ok.
Do you receive ITV HD there? In your area 1.4m Famaval was not big enough for ITV HD so I am expecting the BBC HD transponders to be the same.

QPSK 5.6 requires 6.5 dB SNR minimum.
8PSK 2/3 requires 6.6dB SNR minimum.
8PSK 3/4 requires 7.9dB SNR minimum.

Here I am getting around 12dB SNR on my 1.8m on those transponders so still got plenty in reserve.

Need to get some reports from Brian.

superpascu2

superpascu2

Member
Messages
95
My Satellite Setup
ATLAS HD100 - ASTRA 19,2 + HOTBIRD 13 + 28,2 1.2m famaval
My Location
Alicante
Do you receive ITV HD there? In your area 1.4m Famaval was not big enough for ITV HD so I am expecting the BBC HD transponders to be the same.

QPSK 5.6 requires 6.5 dB SNR minimum.
8PSK 2/3 requires 6.6dB SNR minimum.
8PSK 3/4 requires 7.9dB SNR minimum.

Here I am getting around 12dB SNR on my 1.8m on those transponders so still got plenty in reserve.

Need to get some reports from Brian.
10847V OK with 1.1 favamal in Alicante, also with good margin

No more HD transporders available

Huevos

Huevos

Satellite Freak
Messages
5,994
My Satellite Setup
57E to 58W, C-band and Ku, DVB-S2, 4:2:2 and blindscan.
My Location
38.5ºN, 0.5ºW
Alicante is completely different. LP is in Torre.

superpascu2

superpascu2

Member
Messages
95
My Satellite Setup
ATLAS HD100 - ASTRA 19,2 + HOTBIRD 13 + 28,2 1.2m famaval
My Location
Alicante
Huevos

Huevos

Satellite Freak
Messages
5,994
My Satellite Setup
57E to 58W, C-band and Ku, DVB-S2, 4:2:2 and blindscan.
My Location
38.5ºN, 0.5ºW
He is in the province, not the city. So almost 100 km south.

superpascu2

superpascu2

Member
Messages
95
My Satellite Setup
ATLAS HD100 - ASTRA 19,2 + HOTBIRD 13 + 28,2 1.2m famaval
My Location
Alicante
10847V OK with 1.1 favamal in Alicante, also with good margin

No more HD transporders available
Bad news in bad weather conditions, I lost 10847V 3/4.

But I still receiving all SD and Ch4HD 5/6 and Ch5HD 5/6. So, is it easier to get 5/6 than 3/4 even in HD?

Huevos

Huevos

Satellite Freak
Messages
5,994
My Satellite Setup
57E to 58W, C-band and Ku, DVB-S2, 4:2:2 and blindscan.
My Location
38.5ºN, 0.5ºW
Bad news in bad weather conditions, I lost 10847V 3/4.

But I still receiving all SD and Ch4HD 5/6 and Ch5HD 5/6. So, is it easier to get 5/6 than 3/4 even in HD?
Nothing to do with HD. The difference is between QPSK and 8PSK. For the same FEC, 8PSK needs at least two extra dish sizes.

Tururu

Tururu

Assembled with recycled parts
Messages
2,699
My Satellite Setup
90cm motorised dishes(98x90)+fixed+multiLNB+24Unicable.
Currently 55 satellites, 61°West to 57°East.

DB800S-HD VU+DUO2, VU+Ultimo4K, TBS5925, OctagonSX88.
Recycled as the owner.
My Location
North of Madrid (28703 Spain) -3Km of IKEA (40.545847, -3.612012).:-)
Gibertini125cm, North of Madrid (28703 Spain) -3Km of IKEA (40.545847, -3.612012) .


In summer, change the old Gibertini130 for a second-hand Gibertini125, perfect.
I have to change some wrong lifting screws, they are clogged and I have to cut, but for family issues, in pending tasks.
When assembling and adjusting, 11053H perfect, with the storms I lost it, 11023H23000 3/4 is intermittent, at the moment it is not possible to check.
11068H23000 3/4 with fine rain well, is the most critical of all.
The rest of UK tp without problems.
---------------
En verano cambie la vieja Gibertini130 por una Gibertini125 de segunda mano, perfecto.
Quede en cambiar unos tornillo de elevacion mal, estan gripados y tengo que cortar, pero por temas familiares, en tareas pendientes.
Al montar y ajustar, 11053H perfecto, con las tormentas lo perdi, 11023H23000 3/4 esta intermitente, de momento no es posible revisar.
11068H23000 3/4 con lluvia fina bien, es el mas critico de todos.
El resto de tp UK sin problemas.

Madrid_Gibertini_125_UK1.pngMadrid_Gibertini_125_3az.pngMadrid_Gibertini_125_1.pngMadrid_Gibertini_125_11.pngMadrid_Gibertini_125_3.pngMadrid_Gibertini_125_11023H23000_3-4a.png

Last edited:
Tururu

Tururu

Assembled with recycled parts
Messages
2,699
My Satellite Setup
90cm motorised dishes(98x90)+fixed+multiLNB+24Unicable.
Currently 55 satellites, 61°West to 57°East.

DB800S-HD VU+DUO2, VU+Ultimo4K, TBS5925, OctagonSX88.
Recycled as the owner.
My Location
North of Madrid (28703 Spain) -3Km of IKEA (40.545847, -3.612012).:-)
Nublado, ligera lluvia/Cloudy, light rain. VU+DUO2
10714 = 8.8dB Señal/SNR59% AGC69%
10729 = 8.3dB Señal/SNR55% AGC69%
10758 = 9.5dB Señal/SNR63% AGC69%
10773 = 9.1dB Señal/SNR61% AGC74%
10788 = 9.2dB Señal/SNR61% AGC69%
10803 = 8.8dB Señal/SNR59% AGC69%
10818 = 9.2dB Señal/SNR61% AGC69%
10847 = 9.9dB Señal/SNR66% AGC69%
10891 = 9.7dB Señal/SNR64% AGC74%
10906 = 10.3dB Señal/SNR69% AGC69%
10964 = 10.4dB Señal/SNR69% AGC74%
10994 = 9.9dB Señal/SNR66% AGC74%
11023 =
11053 =
11068 = 8.8dB Señal/SNR59% AGC74%
11097V= ********
11127 = 8.5dB Señal/SNR57% AGC69%
11306H= 9.1dB Señal/SNR51% AGC64%
11307V= 9.0dB Señal/SNR60% AGC69%
11344H= 9.3dB Señal/SNR62% AGC64%
11344V= 8.9dB Señal/SNR59% AGC64%
11386H= 9.1dB Señal/SNR60% AGC64%
11386V= 8.6dB Señal/SNR57% AG64%
11426H= 8.7dB Señal/SNR58% AGC69%
11426V= 9.0dB Señal/SNR60% AGC64%
12129 = 7.5dB Señal/SNR48% AGC69%
12304 = 8.3dB Señal/SNR55% AGC64%
12382 = 8.5dB Señal/SNR0 AGC99%

Lluvia ligera-moderada/Light-moderate rain. VU+DUO2
10714 = 8.5dB Señal/SNR57% AGC69%
10729 = 8.1dB Señal/SNR54% AGC64%
10758 = 9.0dB Señal/SNR60% AGC64%
10773 = 8.6dB Señal/SNR57% AGC67%
10788 = 8.8dB Señal/SNR58% AGC64%
10803 = 8.4dB Señal/SNR55% AGC64%
10818 = 8.9dB Señal/SNR59% AGC69%
10847 = 9.4dB Señal/SNR62% AGC69%
10891 = 9.2dB Señal/SNR61% AGC74%
10906 = 9.9dB Señal/SNR66% AGC69%
10964 = 9.8dB Señal/SNR65% AGC69%
10994 = 9.4dB Señal/SNR63% AGC69%
11023 =
11053 =
11068 = 0.0dB Señal/SNR00% AGC00% **
11097V= ********
11127 = 8.3dB Señal/SNR55% AGC69%
11306H= 9.2dB Señal/SNR61% AGC64%
11307V= 9.3dB Señal/SNR62% AGC64%
11344H= 9.4dB Señal/SNR62% AGC64%
11344V= 9.3dB Señal/SNR63% AGC64%
11386H= 0.0dB Señal/SNR00% AGC00% **
11386V= 8.9dB Señal/SNR59% AGC64%
11426H= 8.7dB Señal/SNR58% AGC64%
11426V= 9.1dB Señal/SNR60% AGC64%
12129 = 7.3dB Señal/SNR48% AGC69%
12304 = 8.7dB Señal/SNR58% AGC69%
12382 = 8.9dB Señal/SNR60% AGC69%

Now only cloudy by Madrid, better signal and quality (13:00 Madrid)
Gibertini 125, IBU 0.2dB.

TonyilCapo

TonyilCapo

Member
Messages
64
Location
над холмами и далеко
My Satellite Setup
Dishes: PF (restored Famaval) 2.4m 28.2E, offset 60cm 30W, 90cm 13E+19E, spares 80cm+1.15m
STBs: Vu+ Vu+ Duo2 DVBS2 x4 1TB HDD, GI Avatar2 DVBS2 x2, Vu+Zero
My Location
Central Portugal
Hi
High band is a little weak for me, but overall pretty good.
Clouds and rain do not change much, unless it's heavy rain.

Turned out to be a good summer investment that old 2.4m dish, I just need to get a proper and specially cheap LNB+Feedhorn.
((if someone have a spare one to sell, Quad, Portugal or Spain, then PM me))
